    Trackers


    GPS geolocation

    RF-TRACK has developed and produced the TRACKER 7 and TRACKER 16.

    TRACKERS 7 and 16 are  compact  and  stand-alone  low  power  modules  with  GPS  /  LoRa functions, designed to be installed on vehicles or assets in order to geolocate them.

    The GPS position sending cycle can be settled Over The Air and the built-in accelerometer can slow down the sending of positions if the tracker is not moving. It also detects STOP and START events.

    Our TRACKERS 7 and 16 are fully compliant with LoRaWan OBJENIOUS and ORANGE networks, and support TDOA location.

    They are also compliant and can be geolocated on the SPOT OBJENIOUS (cartography) platform.



    Find the technical data at the bottom of the page.



    Contact us for more information on our Trackers

    Asset Logger


    Logistic tracking

    RF-TRACK has also developed and produced the ASSET LOGGER which offers, in addition to GPS geolocation, advanced features:



    • Horameter
    • Secure GPRS Link (TLS 1.2 to AWS Server)
    • Configuration via Bluetooth connection
    • Internal backup battery
    • Analog and digital inputs



    Find the technical data at the bottom of the page.

    Technical data


    Tracker 7

    Title

    Awesome way to show your features inside wpbakery page builder.

    Size : 94 x 58 x 25 mm

    Available option:

    Search function*

    View more

    Tracker 16

    Title

    Awesome way to show your features inside wpbakery page builder.

    Size : 110 x 82 x 55 mm

    Available options:

    Configuration by BLE
    Activation/deactivation by NFC
    Search function*
    External power supply
    Digital and analog input/output
    Rechargeable battery

    View more

    Asset Logger

    Title

    Awesome way to show your features inside wpbakery page builder.

    Size : 145 x 66 x 40 mm

    Available options:

    Bluetooth connectivity
    Accelerometer
    Battery backup
    Customized input/output on demand

    View more

    *The “Search” option, available on Trackers 7 and 16, is based on the private RF-Track LoRa protocol. It allows to identify where the Tracker is located (without using the LORAWAN based geolocation). For this functionality, the RFT-LoraSniffer is required.

    Contact us for more information.
